We are one of the highly efficient Exporter of Flat Wire Straightening and Cutting Machines. The company offers high quality range at the Automatic Strip Straightening and Cutting Machine to the clients based in numerous parts of the globe. The Flat Wire Straightening and Cutting Machines are known for their efficiency and can be availed at competitive prices on a timely basis. These machines are fully Automatic Strip Straightening and Cutting Machines. These machnes are used for stnaightening and cutting flat wire.
| Model | FLAT-6 |
|---|---|
| Min. capacity | 0.3mm x 2mm |
| Max. capacity | 1mm x 6mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Cutting Type | Pneumatic |
| Power Required | 2 kw |
| Automation Type | PLC & Servo Controlled |
We are one of the highly efficient Manufacturer Exporter of Flat Strip Straightening and Cutting Machine. The company offers high quality range at the Flat Strip Straightening and Cutting Machine to the clients based in numerous parts of the globe. The Flat Strip Straightening and Cutting Machines are known for their efficiency and can be availed at competitive prices on a timely basis. These machines are Flat Strip Straightening and Cutting Machines. These machnes are used for stnaightening and cutting flat wire.
| Model | FLAT-10 |
|---|---|
| Min. capacity | 1mm x 5mm |
| Max. capacity | 3mm x 10mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Cutting Type | Pneumatic |
| Power Required | 2.5 kw |
| Automation Type | PLC & Servo Controlled |
We are one of the highly efficient Manufacturer and Exporter of Flat Wire Straightening and Cutting Machines in India. The company offers high quality range at the Flat Wire Straightening and Cutting Machines to the client based in numerous parts of India as well as in the globe. The Flat Wire Straightening and Cutting Machines are known for their efficiency and can be availed at competitive prices on a timely basis.
| Model | FLAT-30 |
|---|---|
| Min. capacity | 2mm x 8mm |
| Max. capacity | 3mm x 30mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Cutting Type | Hydraulic |
| Power Required | 6 kw |
| Automation Type | PLC & Servo Controlled |
| Model | FLAT-50 |
|---|---|
| Min. capacity | 3mm x 20mm |
| Max. capacity | 6mm x 50mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Cutting Type | Hydraulic |
| Power Required | 9 kw |
| Automation Type | PLC & Servo Controlled |
| Model | SQUARE-M 04 |
|---|---|
| Square Wire Capacity | From 1.5mm to 4mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Power Required | 2.5 kw |
| Automation Type | PLC & Servo controlled |
| Model | SQUARE-M 10 |
|---|---|
| Square Wire Capacity | From 3mm to 10mm |
| Cutting Length Capacity | From 5mm to 99999mm |
| Feeding Speed | Up to 40 mtrs/min |
| Power Required | 6 kw |
| Automation Type | PLC & Servo controlled |
